Network Forensics & Traffic Analysis

TCP/IP Layers in Forensics

Layer What You Analyze Example Evidence
Application HTTP, DNS, FTP URLs, emails, chats
Transport TCP/UDP Ports, sessions
Internet IP Source/Destination IP
Network Access MAC Device identity

Example:
If a hacker visits a phishing site →

  • Application layer → URL accessed
  • Transport → Port 80/443
  • Internet → Attacker IP
  • MAC → Local device

Packet Structure (VERY IMPORTANT)

Every network packet contains:

  • Header → Metadata (IP, port, protocol)
  • Payload → Actual data (message, file, credentials)

Network Traffic Forensics Lab 04 Tool Used : Wireshark | by Uzma Haneef | Mar, 2026 | Medium

 Example (HTTP Packet):

GET /login HTTP/1.1
Host: example.com
User-Agent: Chrome

 Forensics Goal:
Extract credentials, files, malware, commands

Types of Network Forensics

 1. Live Forensics

  • Real-time monitoring
  • Used during ongoing attacks

 2. Post-Mortem Forensics

  • Analyze stored PCAP/logs after attack

 3. Hybrid Forensics

  • Combination of both

Deep Dive into Tools

 Wireshark (Most Important Tool)

Important Filters (VERY USEFUL)

ip.addr == 192.168.1.1        → Filter IP
tcp.port == 80               → HTTP traffic
dns                         → DNS queries
http.request                → HTTP requests
tcp.flags.syn == 1          → SYN packets (scan detection)

 Key Features:

  • Follow TCP stream
  • Export objects (images/files)
  • Analyze protocols

tcpdump (Command Line)

tcpdump -i eth0
tcpdump -r file.pcap
tcpdump port 80

Zeek (Bro)

  • Advanced logging
  • Detect suspicious behavior
  • Used in enterprises

Snort (IDS)

  • Rule-based detection
  • Detect known attack signatures

Wireshark: Follow Streams | Didier Stevens

Detailed Investigation Workflow

Step 1:  Acquisition

  • Capture traffic using:
    • Wireshark
    • tcpdump
  • Collect logs (firewall, proxy, IDS)

Step 2:  Filtering

  • Remove normal traffic
  • Focus on:
    • Unknown IPs
    • Suspicious ports
    • Large data transfers

Step 3:  Deep Analysis

  • Reconstruct sessions
  • Identify:
    • Malware communication
    • Suspicious DNS queries
    • Data exfiltration

Step 4:  Correlation

  • Match logs + packets
  • Timeline creation

Step 5:  Reporting

  • Evidence documentation
  • Legal admissibility

Digital Forensics Analysis on Different Sources From [12] | Download Scientific Diagram

Advanced Attack Analysis

 1. Phishing Detection

  • Check DNS queries
  • Suspicious domains

2. Malware Traffic

  • Detect Command & Control (C2)
  • Unusual outbound traffic

3. DDoS Attack

  • High number of SYN packets
  • Traffic flooding

4. Data Exfiltration

  • Large outbound data
  • Hidden channels (DNS tunneling)

5. Port Scanning

  • Multiple SYN packets
  • Different ports scanned

7. Important Techniques

 TCP Stream Analysis

  • Reconstruct full communication

 DNS Analysis

  • Detect malicious domains

 File Extraction

  • Extract images, malware

 Timeline Analysis

  • Sequence of attack events

Challenges

  •  Encrypted traffic (HTTPS, VPN)
  •  Huge data volume
  •  Anti-forensics techniques
  •  Cloud & distributed networks

Legal Importance

  • Maintain Chain of Custody
  • Evidence must be:
    • Authentic
    • Reliable
    • Untampered
